    Bronze U-Strap Toggle & Blank

    Bronze U-Strap Toggle & Blank

    • Elegant design
    • Forged from high strength bronze alloy
    • High quality polished chromium finish
    • Stronger than the wire rope
    • Toggle action gives full articulation in two planes
    • Provided with Forged T U Strap toggle design for longer chain plates
    Product Code: UB20

    Show Information for:

    Left Hand Right Hand

    Inch Only Metric Only
    SKU Thread (UNF)Toggle Width (MM)Toggle Width (INCH)Toggle Pin (MM)Toggle Pin (INCH)Adjustment (MM)Adjustment (INCH)
    UB20-14 1/4" 7.6 0.299 6.4 1/4" 76.0 2.992
    UB20-516 5/16" 9.2 0.362 7.9 5/16" 83.0 3.268
    UB20-38 3/8" 10.8 0.425 9.5 3/8" 92.0 3.622
    UB20-716 7/16" 12.3 0.484 11.1 7/16" 100.0 3.937
    UB20-12 1/2" 13.0 0.512 12.7 1/2" 104.0 4.094
    UB20-58 5/8" 18.0 0.709 16.0 5/8" 126.0 4.961
