    Stemball Cup Dimensions
    Stemball Cup
    Stemball Cup Dimensions

    Stemball Cup

    • Manufactured from high specification 316 stainless steel
    • Used to fit Stemball fittings into spreader bracket
    • One or two Stemball cups may be required to bring the head size up to fit the mast/spreader brackets
    Clear
    Add to Quote
    Product Code: 042C

    Show Information for:

    Left Hand Right Hand

    Inch Only Metric Only
    SKU Wire Size (Metric)Wire Size (Imperial)A (MM)A (INCH)B (MM)B (INCH)Weight (KG)Weight (LB)
    042C-4 4 MM5/32"9.00.35426.01.0240.0160.035
    042C-5 5 MM3/16"11.20.44126.01.0240.0140.031
    042C-6/7 6 MM & 7 MM7/32", 1/4", 9/32"16.00.63026.01.0240.0160.035
    042C-8/10 8 MM & 10 MM5/16" & 3/8"20.00.78734.01.3390.0170.037
