    Bronze Fork & Blank

    • Elegant design
    • Forged from high strength bronze alloy
    • High quality polished chromium finish
    • Supplied with a Machined Threaded Fork at one end. For further dimensions, please refer to Threaded Fork End (B16)
    Clear
    Add to Quote
    Product Code: B30

    Show Information for:

    Left Hand Right Hand

    Inch Only Metric Only
    SKU Thread (UNF)Fork Width (MM)Fork Width (INCH)Fork Pin (MM)Fork Pin (INCH)Adjustment (MM)Adjustment (INCH)
    B30-14 1/4" 6.4 0.252 6.2 1/4" 76.0 2.992
    B30-516 5/16" 7.9 0.311 7.7 5/16" 83.0 3.268
    B30-38 3/8" 9.5 0.374 9.3 3/8" 92.0 3.622
    B30-716 7/16" 11.1 0.437 10.9 7/16" 100.0 3.937
    B30-12 1/2" 12.7 0.500 12.6 1/2" 104.0 4.094
    B30-58 5/8" 15.9 0.625 15.6 5/8" 126.0 4.961
    B30-34 3/4" 19.1 0.752 18.5 3/4" 168.0 6.615

    For the most beautiful boats and buildings,
    choose sta-lok.

    We believe that customer service is an extension of the quality products we produce.

    Our technical specialists are on hand to assist with any product or technical queries, or indeed, bespoke or unique requests to help you complete your project.
