    Bronze Fork & Fork

    • Bronze Turnbuckle assembly, supplied with a fully machined Threaded Fork End (B16/B17) at each end
    • Forged from high strength bronze alloy
    • High quality polished chromium finish
    • Stronger than the wire rope
    Clear
    Add to Quote
    Product Code: B31

    Show Information for:

    Left Hand Right Hand

    Inch Only Metric Only
    SKU Thread (UNF)Fully Open (MM)Fully Closed (MM)Fully Open (INCH)Fully Closed (INCH)Fork Width (MM)Fork Width (INCH)Fork Pin (MM)Fork Pin (INCH)
    B31-14 1/4" 225.0 149.0 8.858 5.866 6.4 0.252 6.2 1/4"
    B31-516 5/16" 260.0 177.0 10.236 6.969 7.9 0.311 7.7 5/16"
    B31-38 3/8" 293.0 201.0 11.535 7.913 9.5 0.374 9.3 3/8"
    B31-716 7/16" 333.0 233.0 13.110 9.173 11.1 0.437 10.9 7/16"
    B31-12 1/2" 368.0 267.0 14.488 10.512 12.7 0.500 12.6 1/2"
    B31-58 5/8" 427.0 301.0 16.811 11.850 15.9 0.625 15.6 5/8"
    B31-34 3/4" 547.0 382.0 21.535 15.039 19.1 0.752 18.5 3/4"
